1. Computer automatic control, automatic counting and set counting alarm, high efficiency, saving manpower and time;
2. From film rolling to finished bag, it is fully automatic and one-time;
3. Domestic servo motor has fixed length, photoelectric tracking, accurate and stable, and photoelectric control is adopted for feeding;
Performance and characteristics:
1. Computer automatic control, automatic counting and set counting alarm, high efficiency, saving manpower and time;
2. From film rolling to finished bag, it is fully automatic and one-time;
3. Domestic servo motor has fixed length, photoelectric tracking, accurate and stable, and photoelectric control is adopted for feeding;
4. Adopt hot cutting device and intelligent temperature control system to make the bag mouth sealed firmly and smoothly;
5. The main engine adopts frequency converter to control speed regulation;
6. Rewinding is controlled by PLC;
7. Discharging is controlled by frequency converter;
|
Model |
XG-D500 |
|
Suitable material |
PE,PP,PVC film |
|
Bag making width |
10-400mm |
|
Bag making length |
10-1600mm |
|
Output capacity(pcs/min) |
100-250 |
|
Total power(kw) |
12 |
|
Weight(kg) |
1500 |
